SLIDE 1
A Peek into Paper Conservation
Stephanie Porto Niagara Art Conservation
What is Art Conservation?
Image courtesy of Julie Heath & Ann Creager, Lunder Conservation Center.
A Peek into Paper Conservation Stephanie Porto Niagara Art - - PowerPoint PPT Presentation
A Peek into Paper Conservation Stephanie Porto Niagara Art - - PowerPoint PPT Presentation
A Peek into Paper Conservation Stephanie Porto Niagara Art Conservation What is Art Conservation? Image courtesy of Julie Heath & Ann Creager, Lunder Conservation Center. Damage to Cultural Property Photos courtesy of Samantha Springer (top
SLIDE 2
SLIDE 3
Photos courtesy of Samantha Springer (top left), the Conservation Center for Art and Historic Artifacts (lower right), and the Winterthur/University of Delaware Program in Art Conservation.
Damage to Cultural Property
SLIDE 4
Photos courtesy of the Winterthur/University of Delaware Program in Art Conservation. Lower left and right photos by Lazlo Bodo.
What do conservators do?
SLIDE 5
SLIDE 6
Code of Ethics
Photo courtesy of Corine Norman.
Surface cleaning an Andy Warhol print
SLIDE 7
SLIDE 8
SLIDE 9
Six Primary Activities of Conservation:
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of Stephanie Oman.
SLIDE 10
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of the Art Conservation Department, Buffalo State College.
Six Primary Activities of Conservation:
SLIDE 11
Looking at Paper:
Transmitted Light
Laid paper Wove paper
SLIDE 12
Watermarks
- chiaroscuro
Transmitted light Raking light
- J. WHATMAN
TURKEY MILL 1850
SLIDE 13
Looking at Paper:
Raking and Specular Light
Verso, raking light Recto, oblique specular light
SLIDE 14
Looking at Paper:
Ultraviolet Radiation
Restoration in the sitter’s face absorbs UVA and appears dark Slight yellow fluorescence under the arch indicates zinc white retouching
SLIDE 15
Looking at Paper:
Infrared Radiation
IR Vidicon camera used to visualize a partially hidden inscription
SLIDE 16
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of Julie Heath & Ann Creager, Lunder Conservation Center, Smithsonian American Art Museum & National Portrait Gallery.
Six Primary Activities of Conservation:
SLIDE 17
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of Anya Shutov.
Six Primary Activities of Conservation:
SLIDE 18
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
SLIDE 19
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
Re-adhereing flaking gelatin emulsion on a photograph
SLIDE 20
Consolidation
Gelatin applied by both ultrasonic mist and brush Acrylic adhesive applied by brush and set with heat
SLIDE 21
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
Grated vinyl eraser crumbs used to gently and evenly remove surface dirt
SLIDE 22
Surface Cleaning / Varnish Removal
Unwashed support prone to tidelines
Surface grime reduced by swabbing with distilled water; varnish reduced by swabbing with ethanol
SLIDE 23
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
Removing an acidic corrugated cardboard backing that was adhered overall to a large drawing
SLIDE 24
Facing
Unwashed support prone to tidelines
Carbopol and Ethomeen mixed with ehtanol, applied over Japanese tissue
Japanese tissue adhered to stabilize torn and fragmented areas during treatment
SLIDE 25
Backing removal
Two textile backings removed by tearing away in strips
SLIDE 26
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
Immersion washing an etching
SLIDE 27
Localized washing and stain reduction
Localized suction treatment of banded discoloration (left) and tape stains (right).
SLIDE 28
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
Wet paste lining performed to stabilize a drawing previously backed with corrugated cardboard
SLIDE 29
Consolidating flaking media Reinforcing holes caused by corrosive pigments
Stabilization
SLIDE 30
Restoration
Japanese woodblock print before treatment (left), after overall bleaching (centre), and after spot bleaching.
SLIDE 31
- Consolidation
- Surface cleaning
- Backing removal
- Washing
- Lining
- Compensation
for loss
Common Interventions
During treatment After treatment
Inpainting pulp fills to restore lost image
SLIDE 32
Loss Compensation
Before compensation Losses toned with dry pigment and pastel media Map of the City of Buffalo (detail) Hand-coloured lithograph 1833
SLIDE 33
Fine Art vs. Archival Material
Untitled Norval Morrisseau Acrylic on paper 1969 Sympathy certificate for widow
- f Burr Plato
Gelatin silver photograph 1909
SLIDE 34
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of Anya McDavis-Conway.
Conservator measuring light levels
Six Primary Activities of Conservation:
SLIDE 35
Preventive Conservation Includes:
- Proper handling
- Packing and transport
- Housing/storage
- Monitoring the environment
- Conducting surveys and assessments
- Preparing for emergencies
- Guidelines for use of artifact or collection
SLIDE 36
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of the Winterthur/University of Delaware Program in Art Conservation.
Six Primary Activities of Conservation:
SLIDE 37
- Examination
- Documentation
- Treatment
- Preventive Care
- Research
- Education
Photo courtesy of Winterthur/University of Delaware Program in Art Conservation. Photo by Joyce Hill Stoner.
Six Primary Activities of Conservation:
SLIDE 38
Rotary Club Charter – Before treatment
SLIDE 39
Rotary Club Charter – Before treatment
Raking light
SLIDE 40
- 1. Surface clean
- 2. Wash
- 3. (Locally bleach)
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
SLIDE 41
- 1. Surface clean
- 2. Wash
- 3. (Locally bleach)
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
Removing dried mold structures using a HEPA filtered vacuum
SLIDE 42
Removing surface dirt using grated vinyl eraser crumbs
SLIDE 43
- 1. Surface clean
- 2. Wash
- 3. (Locally bleach)
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
Immersion washing in pH balanced water
SLIDE 44
Before treatment After washing
SLIDE 45
After washing After ACD treatment
SLIDE 46
- 1. Surface clean
- 2. Wash
- 3. Locally bleach
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
Reducing bleach brushed onto distracting tideline stain
SLIDE 47
After ACD treatment After local bleach
SLIDE 48
- 1. Surface clean
- 2. Wash
- 3. Locally bleach
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
Mold damaged areas treated with a water and ethanol solution on the suction table
SLIDE 49
- 1. Surface clean
- 2. Wash
- 3. Locally bleach
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
Creases burnished flat on the suction table
SLIDE 50
- 1. Surface clean
- 2. Wash
- 3. Locally bleach
- 4. Disinfect mold
- 5. Humidify / flatten
- 6. Attach hinges
Treatment Plan
Japanese paper hinges attached to facilitate matting and framing
SLIDE 51
Before treatment After treatment
SLIDE 52
Before treatment After treatment
Raking light
SLIDE 53
Acknowledgements
- Many thanks to the private collectors and institutions
whose artifacts were entrusted to my care and appear in this presentation. They include the Metropolitan Museum
- f Art, Buffalo and Erie County Public Library, Niagara
Falls History Museum, and Niagara Historical Society.
- Thank you also to The American Institute for
