Activities and Plans in the US Paul M. Grant W2AGZ Technologies San Jose, CA USA A Sober Assessment of Opportunities and Realities http://www.w2agz.com/BD_3TUW09.htm New Holland & The Hudson Valley Barents Baltus (1659) > Baltus

slide-1
SLIDE 1

Activities and Plans in the US

Paul M. Grant W2AGZ Technologies San Jose, CA USA “A Sober Assessment of Opportunities and Realities”

http://www.w2agz.com/BD_3TUW09.htm

slide-2
SLIDE 2

New Holland & The Hudson Valley

Barents Baltus (1659) > Baltus Barents van Kleeck (?)(1702) > Poughkeepsie

slide-3
SLIDE 3

US Electric Power 101

slide-4
SLIDE 4
  • ~$2 trillion total asset value
  • $344 billion annual revenues
  • 142 million customers
  • 3273 utilities

Without electric power the $14.3 trillion U.S. economy would come to a halt

‐ Electricity Today ‐

The Crown Jewel of the US Economy

slide-5
SLIDE 5

NYC circa 1890s

slide-6
SLIDE 6

Fathers of American Electric Power

slide-7
SLIDE 7

The US Electrical System

slide-8
SLIDE 8

US Electricity Generation Sources

slide-9
SLIDE 9

US Electricity Flow ‐ 2007

1 Quad = 0.29 TkWh US Generation Capacity = 1.1 TW Gross Generation = 4.33 GkWh (T&D Losses)/(End Use) = 10%

slide-10
SLIDE 10

The US Transmission Grid(s)

  • 300,000 km
  • 500 companies
  • 10% Losses
slide-11
SLIDE 11

North American HVDC

slide-12
SLIDE 12

Pacific Intertie

  • HVDC, +/‐ 500 kV, 3.1 kA, 3.1 GW
  • 1,362 km
  • ~50% of LA Power Consumption
  • Converter/Inverter Losses ~ 5%
  • Ohmic Losses ~ 10%

Celilo I/C Station “A Mountain of Silicon”

slide-13
SLIDE 13

NERC Interconnects

Source: DOE 2006 National Electric Transmission Study

slide-14
SLIDE 14

The Grid:

A Journey Though the Heart of Our Electrified World

By Phillip F. Schewe Joseph Henry Press, 2007 (Buy It!) Reviewed by Paul M. Grant:

Plugged into the matrix

The rise and potential fall of the US electricity grid

Nature 447, 145 (2007)

http://www.w2agz.com/Publications/Book%20Reviews/06%20%282007%29%20Plugged%20Into%20the%20Matrix.pdf

slide-15
SLIDE 15

Where Can We Use Superconductivity?

Potentially Everywhere

…maybe

slide-16
SLIDE 16

Superconductivity Act of 1988

DOE Program: ~ 20 Years @ ~ $50 M/yr = $1 B

slide-17
SLIDE 17

HTSC Utility Market

10 More Years!

slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27

2010 DOE OED&ER Budget Request

?

WOW !

slide-28
SLIDE 28

Wiring the World with Copper Oxides

slide-29
SLIDE 29

HTSC Power Technology is Here

  • …and it works!

– …perhaps still a little pricey, though

  • …so where’s the demand?
  • …what needs to be fixed?
  • …why isn’t is being used?

– …would it help if the wire/tape were free?

slide-30
SLIDE 30

Projected 2008 Congested Paths in the Eastern Interconnection

Source: DOE 2006 National Electric Transmission Study

slide-31
SLIDE 31

Western Interconnection

Source: DOE 2006 National Electric Transmission Study

slide-32
SLIDE 32

Real‐Life Power Flows

Can we defeat (macroscopically) Kirchhoff's Laws?

slide-33
SLIDE 33

Chaos on the Grid

Business as usual Business when a crowbar is thrown across the lines

slide-34
SLIDE 34

How many 9’s?

  • Average rms Voltage = 116.25 volts
  • Deviation = +/- 3.0 volts
  • Percentage = ~ 3.5%
  • Not Exactly “Five 9’s”

“Easily accommodated by most PC power supplies…no problem.”

07/25/04 3:30‐6:00 PM, Sunday, SJ, CA 95120‐‐W2AGZ Server Voltage

slide-35
SLIDE 35

San Francisco ‘00 Chicago ‘99 New Orleans ‘99 Atlanta ‘99 Delaware ‘99 New York ‘99 Detroit ‘00 West Coast ’96

18 18 17

San Francisco ‘00 Chicago ‘99 New Orleans ‘99 Atlanta ‘99 New York ‘99 Detroit ‘00 West Coast ’96 Northern California ‘01 Delaware ‘99 Texas ‘03

Blackouts

Northeast ‘03

slide-36
SLIDE 36

Northeast 8/14/03

slide-37
SLIDE 37

As Night Falls…

slide-38
SLIDE 38

The Party Begins…

slide-39
SLIDE 39

…and Continues…

slide-40
SLIDE 40

It Gets Better…

slide-41
SLIDE 41

and Better…

slide-42
SLIDE 42

The Morning After

slide-43
SLIDE 43

Viva New York!

slide-44
SLIDE 44

Can “New” Transmission Technology Help?

  • Yes, but probably not superconductivity in a

big way, at least for a while.

  • More likely, “smart” grid stuff will come first

– HVDC cables and lines – FACTS to increase present corridor capacity by 30% – IT and communications plus an “OS/360” to more effectively and efficiently management power flows

  • P. M. Grant, DOE Presentation, 2004
slide-45
SLIDE 45

Financials

$750 M ($400 M “VC”, $350 M “Futures”)

  • Loan Payment (4%, 40 yrs, 750 M$) = 35 M$/yr
  • Labor, Overhead, Maintenance = 5 M$/yr
  • Tariff =

0.5 ¢/kWh

  • Profit (NOI) @ 50% Capacity =

4 M$/yr

  • Profit (NOI) @ Full Capacity =

48 M$/yr

Specifications

2-1000 MW HVDC Bipolar Circuits

  • Circuit 1: 130 miles, Greene County → Bronx County
  • Circuit 2: 140 miles, Albany County → New York County
  • Each Circuit: +/- 500 kV, 1000 A Bipolar (2 cables ea.)

Why didn’t it go forward?

Wire C/P = 100 $/kA×m HTSC Cost = $87 M

slide-46
SLIDE 46

Sayerville, NJ → Levittown LI, NY ‐ 600 MW (+/‐ 250 kV, 1200 A) ‐ 65 miles (105 km) ‐ $400 M ‐ 2007 Pirelli (Prysmian) Energy Cables $190 M T 77 K C/P $/kA×m Cost ($M) Cu 7 1.8 HTSC 100 25.1

Financials 40 yrs @ 4%: $ 20M LOM: 1 M NOI (100%): 5 M

slide-47
SLIDE 47

So Where’s the “Gold Rush” to Superconductivity?

  • What’s the analogy to the Erie Canal,

Railroads, REA, TVA, Interstate Highways that

  • pened the country to economic

development?

– Capacity? Possibly – Reliability? Maybe – Power Quality? Nah

slide-48
SLIDE 48
slide-49
SLIDE 49
slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52
slide-53
SLIDE 53
slide-54
SLIDE 54
slide-55
SLIDE 55
slide-56
SLIDE 56

1250 Miles 4 GW 460 Miles 500 kV

slide-57
SLIDE 57
slide-58
SLIDE 58

“Superconduct-ress”

slide-59
SLIDE 59
  • Mr. Electric Utility Good Ol’ Boy
slide-60
SLIDE 60

Miss Same Old Technology

slide-61
SLIDE 61

Together Forever?

slide-62
SLIDE 62
