Airly Mine

Airly Mine

Community Consultative Committee (CCC) Presentation Airly Mine 5th September 2017

• 1. Introduction

Reporting Period: May - Sep 2017 Site Name/Location: Airly Mine, Capertee, NSW Summary of Consents and Licences: Airly Mine Contact Details:

2

Any Change? SSD_5581 No ML1331 No EPL12374 No A232 No EPBC 2013/7606 Approval granted on 18 May 2017 Position Key Contact Contact Details Mine Manager Bob Miller (02) 6359 2101 Email: bob.miller@centennialcoal.com.au Environment and Community Coordinator Sam Price Office: (02) 6359 2108 Mobile: 0427 647 657 Email: sam.price@centennialcoal.com.au

• 2. Operations Summary

Material Approved Limit (and source) This Reporting Period since previous CCC (May – Aug 2017) Year to Date Annual Forecast Waste Rock/ Overburden

N/A N/A N/A N/A

ROM Coal

1.8MT/annum 259kt 522kt 850kt

Reject

N/A N/A N/A N/A

Saleable Product

N/A 190kt 263kt 850kt

Railing

224kt 464kt 840kt

3

4

Current & Projected Workings

5

Current & Projected Workings

Overview of Operations 2017 YTD

• Nil environmental “non compliances” recorded
• Production and productivity levels exceeded both budget and

forecast

• Successful trial of gate road ‘single unit’ development completed at

increased depth under Airly Mesa

• ‘Super unit’ development extended into shallow workings on

western fringe of Genowlan Mesa

• Permanent employment numbers increased from 78 to 82 persons
• Continued to supply domestic customers (Eraring and Delta) and

export customers through Port Waratah Coal Services.

• Undertook major upgrade of underground ventilation infrastructure
• Commitment resources to continuous miner rebuild program,

underground ventilation and conveyor upgrade

• Developed environmental management plans under SSD_5581

6

Projections for 2017 Operating Context

• Maintain bord and pillar first working operations

employing ‘super unit’ methods in 206 Panel and 207 Panel under Genowlan Mesa

• Undertake gate road development program under Airly

Mesa employing “single unit” methods.

• Gain regulatory approval for conditions contained in the

consent granted for the Airly Extension Project..

• Finalise feasibility report for Phase 2 Mining including:
• Option study on equipment selection near finalisation
• Capital project funding documentation prepared
• Rebuild program commenced for continuous miners

7

• 3. Environmental Performance

8

Airly Mine – Noise Monitoring

• Airly Mine has no specific noise monitoring requirements or noise criteria in either

the Project Approval (DA 162/91) or EPL12374.

• Airly Mine is currently preparing a Noise Management Plan (NMP) in accordance

with SSD_5581.

• 2017 noise monitoring is scheduled for October.

9

Airly Mine Adopted Noise Monitoring Criteria Location Day/Evening/Night Criteria. LAeq, 15minute Night Criteria. LA1,1minute Location A N/A N/A Location B 35 45 Location C N/A N/A Location D N/A N/A Location E N/A N/A Location F N/A N/A

Airly Mine – Noise Monitoring Results

Location Compliant? Location A IA <30 IA N/A Yes Location B IA IA IA 35 Yes Location C <30 35 <20 N/A Yes Location D IA IA IA N/A Yes Location E IA <25 IA N/A Yes Location F IA <30 <30 N/A Yes

10

• LAeq,15minute noise monitoring was conducted at Airly Mine on 13th & 14th

November 2016 for locations A, B and D; and on 20th and 21st November 2016 for locations C, E and F.

IA = Inaudible

Airly Mine – Air Quality Monitoring Results

11

Location Air Quality (g/m2/month) Dust Deposition Gauge Results

Jan 2017 Feb 2017 Mar 2017 Apr 2017 May 2017 Jun 2017 Jul 2017 Aug 2017

DM1

0.8 0.4 2.4 0.6 0.4 0.8 0.1 0.3

DM2

1 4.2* 0.6 0.3 0.2 0.1 0.2 0.3

DM3

0.4 1.2 0.7 2.6 0.7 0.3 0.5 0.3

DM4

2.2 1.5 0.5 0.3 0.3 0.1 0.2 0.2

Non-compliance Compliance

• *Sample contaminated by external factors such as bird droppings.
• Airly Mine has four depositional dust gauges located across site. These gauges are

monitored monthly for compliance.

• Depositional dust monitoring results for YTD 2017 are provided below.

Airly Mine – Air Quality Monitoring Results

12

Airly Mine - Meteorological Monitoring

13

Month Total Rainfall (mm) Minimum Temperature (

• C)

Maximum Temperature (

• C)

January – 2017 37.4 11.7 38.3 February – 2017 20.8 5.4 41.4 March – 2017 130.6 8 30 April – 2017 21.8 1.6 22.3 May – 2017 28.4

• 3.7

19.7 June – 2017 16.6

• 2.4

16.8 July – 2017 8

• 5.5

20.7 August – 2017 Month not complete at the time of the report.

Airly Mine - Meteorological Monitoring

14

Airly Mine – Water Monitoring Results

15

Discharge water quality

pH Total Suspended Solids (mg/L) Electrical Conductivity (μS/cm) Oil & Grease (mg/L)

January 2015 – August 2017 LDP1 No discharge LDP2 No discharge LDP3 No discharge Non-compliance Compliance

Airly Mine – Subsidence Monitoring

• The subsidence monitoring line over the 121 Panel was

installed during February 2017.

• Pillar monitoring in 121 Panel under the subsidence line

was also during February 2017

• Extraction in this area will be later in 2017
• Quotes are being sourced for photogrammetry survey

16

Subsidence Monitoring Line

17

2016 Groundwater Monitoring Bores

18

Monitoring Location Monitoring Type Final Depth Completion Date

ARP11 Lithgow Seam water level & quality 15.29m 13/10/16 ARP12 Grotto surface/ alluvial water level & quality 2.6m 13/10/16 ARP13 Shoalhaven Group (120m bgl) & Devonian strata (280m bgl) water level & quality 310m 9/12/16 ARP13 SP Lithgow Seam water level & quality 80m 25/11/16 ARP14 Oasis surface/ alluvial water level & quality 2.29m 13/10/16 ARP15 Lithgow Seam (125m bgl), Shoalhaven Group (200m bgl), Devonian strata (365m bgl) water level & quality 375m 12/1/17 ARP15 SP Narrabeen sandstone water level & quality 22.2m 17/1/2017

Airly Mine – Groundwater Monitoring Locations

19

• 4. Environmental Management

20

Airly Mine – Cultural Heritage

21

Historically: Five (5) sites have been undermined: 45-1-2746 (Artefact Scatter) - Dec 2010 45-1-2763 (Artefact Scatter) – Mar 2011 45-1-2761 (Shelter) – Jul 2011 45-1-2762 (Artefact Scatter) – Sep 2015 45-1-2748 (Isolated Find) – May 2017

• No mining related disturbance to any site.

Previous 6 Months: One site (45-1-2748) was undermined; monitoring inspections were carried out as per the ACHMP Upcoming 6 Months: Nil Low level subsidence and tilt as a result of mining, does not pose a risk of harm to these sites Fencing activities completed to help mitigate against potential harm

Airly Mine – Cultural Heritage

22

• A pre-mining inspection of site 45-

1-2748 was completed on 28 March 2017.

• No mining induced impacts to

the site were evident during the pre-mining inspection

• A post-mining inspection of site 45-

1-2748 was carried out on 17 August 2017.

• No mining related disturbance

were evident during the

• inspection. All RAPs were

satisfied with the condition of the site.

Airly Mine – Rehabilitation & Land Management

• Airly Mine does not currently have any land available or subject to rehabilitation
• works. This is not likely to change until mine closure.
• Updated rehabilitation cost estimate was sent to DRE on 31 March 2017.
• A revised MOP/RMP has been developed and has been submitted for consultation

and approval.

• Spring/Summer 2017-18 weed spraying program will recommence in October.
• Surrounding Mine owned land continues to be leased out for agricultural purposes.
• Riparian restoration of Airly Creek on-going. Tube stock scheduled for Spring.
• Tree screen maintenance conducted as required.

23

Airly Mine – Flora, Fauna & Aquatic Ecology Monitoring

24

• Flora and fauna monitoring activities are

conducted by RPS in spring and summer.

• Aquatic ecology monitoring activities were

conducted in May 2017. And are scheduled again for October 2017.

• Stygofauna monitoring was conducted in

August 2017. No stygofauna present.

Glossy-black Cockatoos Leaf-tailed Gecko

• 5. Summary of Incidents / Non-compliances

(CCC Period: Feb - Apr 2017)

Were all conditions of the relevant approval(s) complied with?

DA162/91 YES ML1331 YES EPL12374 YES A232 YES

25

Statement of Compliance:

Relevant Approval Condition # Condition summary Compliance Status Comment / Description Nil

Non-compliance Summary: Incident Summary:

Nature of Incident Detail of Incident Detail of Mitigation / Remediation

Nil

• 6. Community Engagement
• Airly Mine representatives attended and provided updates at the Capertee Valley

Progress Association (CVPA) Monthly Meetings;

• Airly Mine manned the BBQ again for the Train Day Market on Sunday 21 May

2017.

26

Sponsorship/Donations:

• Kandos/Rylstone Show;
• Rylstone Street Feast;
• Capertee Public School;
• Capertee Hall.
• Cudgegong Country Ball
• Rylstone Rural Fire Brigade

• 7. Community Complaints
• One community complaint was received on 10 March 2017 in relation to vibration.
• Airly Mine Community Complaints Register is publically available on the Centennial

Coal website.

27

Community Complaints Register 2017.

Jan

• 17

Feb

• 17

Mar

• 17

Apr

• 17

May

• 17

Jun

• 17

Jul- 17 Aug

• 17

Sep

• 17

Oct

• 17

Nov

• 17

Dec

• 17

Jan

• 18

Total

Air Water Noise Other

1

Subsidence Waste Visual 1

• 8. Activities proposed for the Next Period

 Environment

• Scheduled monitoring and reporting

 Systems

• Continue to prepare environmental management plans.
• Implementation of compliance database.

 Water

• Routine monitoring and reporting

 Rehabilitation and Mine Closure

• Nil

 Biodiversity

• Routine monitoring and reporting

 Approvals

• Awaiting approval of submitted environmental management plans as

required under SSD_5581

• Submit Extraction Plan for First Workings in the Cliff Zone

28

AIRLY MINE

THANK YOU
