Analytical Query Processing

Marco Serafini

COMPSCI 532 Lecture 7

22

Announcement

• Midterm date and location confirmed
• October 22 at 7-9pm in ILC S331

3

MapReduce vs. DBMSs

44

Advantages of DBMSs

• Abstract data representation
• Relational model
• Data storage is delegated to the DBMS
• Functional query language (SQL)
• Queries specified as simple relational operators
• Actual query execution delegated to the DBMS…
• … including parallelism, distribution, pipelining etc.
• Support for indexing

55

Disadvantages of DBMSs

• SQL is a limited interface for complex analytics
• E.g. image analysis, creating maps
• Need to define a schema for data a priori
• High cost of loading data and indexing
• Can be amortized only if same data and schema reused
• Too complex for “one shot” analytics

66

Advantages of MapReduce

• Support for arbitrary UDFs
• Support for a variety of arbitrary data formats
• Simple API
• Scalability

77

Disadvantages

• Many of the optimizations of DBMS must be

reimplemented, for example

• Indices
• Query execution plans (logical + physical)
• Column-based storage
• Data format specifications (ProtoBuf)
• Support for updates
• Several efforts towards closing the gap for analytics

8

Data Analytics

9

9

In Situ Analytics

• Data dumped on GFS/HDFS (data lake)
• Some of this data is relational
• Several systems to execute relational queries on

HDFS data

• SQL-like language
• Query optimization
• Columnar data representation
• Can build on top of MR/Spark (e.g. Hive, SparkSQL)
• r not (e.g. Dremel, Impala, Presto)
• We will discuss both classes

10

10

Analytical Queries

• Long-running, complex queries
• Often aggregates
• Run on read-only data or snapshots of dynamic data
• Data characteristics
• Tuples (rows) have many possible attributes (columns)
• A row will have only a subset of attributes set

11

11

Star Schema: Facts and Dimensions

• Popular schema for analytics/data warehousing
• Many others exist!
• At the center is a large fact table
• Foreign-key references to small dimension tables

12

13 13

Dremel

• In-situ analytics
• Independent query executor (not on top of MR)
• Uses columnar store

14

14

Data Model: Column Families

• Also called column groups, nested columns
• Common to many systems, e.g. Cassandra, HBase

New record Nested in repeated Language Nested in repeated Name

15

15

Assembling a Row

• Finite state machine

16

16

Pros and Cons of Columnar Model

• Pros
• Compression: columns have uniform values
• Less data to scan on projections (which are common)
• Cons
• Additional CPU load to decompress columns and rebuild rows

17

17

Query Execution

19 19

SparkSQL: Spark + DBMS

• Extend Spark with
• Simple, high-level SQL-like operators
• Query optimization
• No need to transfer data across systems
• ETL, query processing, complex analytics in one system

20

20

Architecture

21

21

DataFrames

• Collection of rows with homogeneous schema
• Like a table in a DBMS
• Can be manipulated like an RDD
• DataFrame operations
• Similar to Python Pandas or R data frames
• Evaluated lazily (query planning is postponed)
• Can optimize across multiple queries

22

22

SparkSQL Query Execution

23

23

Advantages

• Relational structure enables query optimization
• In-memory caching using columnar representation
• Better compression
• Mix SQL-like operators and arbitrary code
• More flexible than UDFs in DBMSs
• Can optimize across multiple SQL operations

24

24

Catalyst

• Query optimizer of SparkSQL
• Rule-based optimization
• Rule: find pattern and transform
• Used for both logical and physical plans
• Can customize rules
• Code generation
• Directly outputs bytecode (as opposed to interpreting a plan)
• Much more CPU efficient
• Flexible data sources
• Can change the physical representation of DataFrames
• Still use the optimizer

25

25

Catalyst: Rule-Based Optimization

• Apply rules to subtree until fixed point

Execution tree Transformation rules

26

26

Catalyst: Code Generation

• Faster than interpreting a physical plan
