Introduction Method Parameter Estimation GW In CUHK Backup Slide Constraining Lorentz Violation of Gravitational Waves with Lensing Adrian K.W. Chung and Tjonnie G.F. Li 1 1 Department of Physics, The Chinese University of Hong Kong,

SLIDE 1

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Constraining Lorentz Violation of Gravitational Waves with Lensing

Adrian K.W. Chung and Tjonnie G.F. Li 1

1Department of Physics, The Chinese University of Hong Kong,

Long-Term Workshop on Gravity and Cosmology, Yukawa Institute for Theoretical Physics, Kyoto University, 6th Febrauary, 2018

1/17

SLIDE 2

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Introduction

Method

Parameter Estimation

GW In CUHK

2/17

SLIDE 3

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Dispersion of Gravitational Waves With h = c = G = 1 Without Lorentz violation: ω = k (1) Isotropic dispersion [1]: E2 = p2 + m2

g + Apα

⇒ ω2 = k2 + m2

g + Akα

⇒ vg(f) ≈ 1 − 1 2m2f−2 − 1 2Afα−2 (2)

3/17

SLIDE 4

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Geometry of the Lensing1

1Figure 1. from R. Takahashi et al. "Arrival time differences between

gravitational waves and electromagnetic signals due to gravitational lensing". ApJ 835 (Jan. 2017), arXiv:1606.00458

4/17

SLIDE 5

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Lensing (Diffraction) of Gravitational Waves Lensed waveform ˜ hL(f) = F(f; lensing parameters)˜ h(f) (3) Amplification function [2]: F(f; θs) ∝ (1 + zL)f i

d2θ exp(2πiftd(

θ, θs)) (4) where td is the arrival time delay between lensed and unlensed rays. Time delay: td( θ, θs) = (1 + zL) c

DLDS

2DLS | θs − θ|2 − ψ( θs)

5/17

SLIDE 6

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Effect due to lensing

102 103

f (Hz)

10−28 10−27 10−26 10−25 10−24 10−23 10−22

|h(f)|

unlensed lensed by ML = 400M⊙ at y = 0.5

6/17

SLIDE 7

Introduction Method Parameter Estimation GW In CUHK Backup Slide

The Central Question

How would the lensing pattern look like if gravitational waves are with dispersions?

7/17

SLIDE 8

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Arrival Time Delay With dispersion td → c vg(f)td (6) From now on β(f) = c/vg(f) Dispersion changes the phase differences along the rays. ⇒ lensing pattern is changed.

8/17

SLIDE 9

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Amplification Functions For point mass lens F(f; y) = exp π 4 wβ w 2 β i w

2 β

× Γ

1 − iw

2 β

2 β, 1; iw 2 βy2 (7) where w = 8πML(1 + zL)f, (7) can be reduced to known case [3] when there is no dispersion.

9/17

SLIDE 10

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Image Pattern

102 103

f (Hz)

0.0 0.5 1.0 1.5 2.0 2.5 3.0

|F(f)|

Dispersionless, m = A = α = 0.0 Dispersive, mg = 0.0, A = 100.0, α = 0.5

(a) |F(f)|

102 103

f (Hz)

10−28 10−27 10−26 10−25 10−24 10−23 10−22

|h(f)|

Dispersionless, m = A = α = 0.0 Dispersive, mg = 0.0, A = 100.0, α = 0.5

(b) |h(f)|

10/17

SLIDE 11

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Parameter Estimations λg = /mgc

15.0 15.5 16.0 16.5 17.0 17.5 18.0

log λmg [m]

0.0 0.2 0.4 0.6 0.8 1.0

Cumulative Posterior Probability

lensed by ML = 400M⊙ at y = 0.5 unlensed

(c) dL = 200 Mpc

15.0 15.5 16.0 16.5 17.0 17.5 18.0

log λmg [m]

0.0 0.2 0.4 0.6 0.8 1.0

Cumulative Posterior Probability

lensed by ML = 400M⊙ at y = 0.5 unlensed

(d) dL = 100 Mpc

11/17

SLIDE 12

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Advantages Relies solely on the lensed signals. SNR of signal is boost. Improved constraint on mg

12/17

SLIDE 13

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Summary Lensing pattern of gravitational waves with dispersions ⇒ probe dispersion using lensing. Better constrains on mg Systematic run is on going. Will have more complete results soon. Incorporating the SIS.

13/17

SLIDE 14

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Our Awesome Group!

14/17

SLIDE 15

Introduction Method Parameter Estimation GW In CUHK Backup Slide

References 1 Saeed Mirshekari et al. "Constraining Lorentz-violating, modified dispersion relations with gravitational waves".

Phys. Rev. D 85, 024041. (Jan. 2012)

2 Schneider, et al (1992). "Gravitational Lenses".Springer’s

Publications. ISBN: 0941-7834. DOI:

10.1007/978-3-662-03758-4 3 R. Takahashi et al. "Wave Effects in the Gravitational Lensing of Gravitational Waves from Chirping Binaries". ApJ 595 (Oct. 2003), pp. 1039-1051. eprint: astro-ph/0305055.

15/17

SLIDE 16

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Overlap Plots

360 380 400 420 440

ML(M⊙)

1 2 3 4 5 6

A (c = h = 1)

×10−43 0.96 . 9 7 0.99 0.2 0.4 0.6 0.8 1.0

Overlap

(e) α = 0

360 380 400 420 440

ML(M⊙)

1 2 3 4 5 6

A (c = h = 1)

×10−30 . 9 6 . 9 7 0.99 0.2 0.4 0.6 0.8 1.0

Overlap

(f) α = 0.5

16/17

SLIDE 17

Introduction Method Parameter Estimation GW In CUHK Backup Slide

Unlensed Dispersive GWs [1] Propagation time delay when A = 0 ∆t = (1 + z)

∆te + m2

2 D0 1 f2

− 1 f′2

This leads to a phase difference, δΨ(f) = − πD0m2

(1 + z)f (9) such that hdisp(f) = h(f)eiδΨ(f) (10)

17/17
