• 1. VESSEL WORK SUMMARY

Ø UNCLE JOHN is a Semi-Submersible, Dynamically Positioned (DP-2) Multi Service Vessel (MSV) with a 16- man saturated diving complex. Ø It is designed to work in harsh water environment, stable and has capabilities to perform in platform recoveries, floatel operations, subsea construction as well as well interventions. Ø The semi-submersible design allows the vessel to be less affected by the sea-state, allowing greater capability to perform tasks in up to 3m seas. Ø It has a 150 MT heaved compensated derrick, positioned Aft Amidship that operates through a moon- pool with a drill floor capable of skidding open to allow well interventions and P&A works in water up to 5,000 ft.

ttttttt gggg jjjjjjjjjjj www deeeee

Uncle John Holding LLC

3

• 2. VESSEL GENERAL SPECIFICATION

REGISTRATION: Port of Registry: Panama Flag: Panama Classification: DNV class MAIN CHARACTERISTICS: Overall Length: 77.0m (252.64 ft) Beam: 52.6m (172.67 ft)

• Max. Speed:

7 knots Displacements: 10514.9 T Operating Draft: 51 ft Transit Draft: 21 ft Clear Deck Space: 11.840 ft sq Deck Load: 385 MT Gross Tonnage: 6947 T Net Tonnage: 2084 T Power Supply: 9175 kW

Uncle John Holding LLC

4

• 3. MAIN PROPULSION / THRUSTERS & DYNAMIC POSITIONING SYSTEM

DYNAMIC POSITIONING: GE Converteam DPS 21 – Duplex DP + IJS; Reference system includes: 1 x Tautwire; 1 x Sonardyne Ranger 1 HPR; 1 x Sonardyne Ranger 2 HPR; 3 x DGPS; 1 x MDL Fan beam. MAIN PROPULSION & THRUSTERS: Self Propelled; Dynamically Positioned with 2 X 3,000hp stern thrusters, 6 X 1000hp transverse thrusters.

Uncle John Holding LLC

5

• 4. DIVING SYSTEM

DIVING SYSTEM (SURFACE & SATURATION): Ø AIR-DIVING:

• Air diving station located on “Veranda” Deck Level on the port

side

• 2 Air Driven surface diving stages with clump weights
• 2 X Surface Decompression Chambers are available for

Surface Decompression Diving Ø SATURATION DIVING:

• 3-man Diving Bell rated at 300msw, launched on a cursor rail

system which allows diving to continue even in rough water

• 4 X 4-man diving chamber which enable numerous diving

scenario with multiple teams available

• 16-man self-propelled hyperbaric lifeboat connected to diving

complex

Uncle John Holding LLC

6

• 5. ACCOMMODATION

ACCOMMODATION: Consists of 3 decks for 102 POB; Ventilation supplied by a LEMMKUHL A/C system. UPPER DECK: 2 x 2 person Cabins; Gyro Room; Transit Bridge. TWEEN DECK: 4 x 1 person Cabin; 26 x 2 person Cabins; Laundry; Linen Locker; Steward Locker; Ships & Clients’ Office; Hospital; E.T store & workshop. HELI-DECK: Approved DNV “D” value of 22.2m and 20,515 lbs; Able to accommodate S-61 air-craft. LOWER DECK: 21 x 2 person Cabins; Sauna; Smoking and Non-Smoking / Lounge Television rooms; Mess Room (54 person); Satellite mess-room (24 person); Bond Store; Break room / Changing Room; Galley; Refrigerated Storage Area; Gym.

Uncle John Holding LLC

7

• 6. DECK EQUIPMENT

MAIN CRANES: 2 x Aker 100 tonne offshore cranes HOISTING CAPACITY: Ø FORWARD CRANE:

• 100 tonnes at 11m radius ; 50 tonnes at 19m radius

Ø AFT CRANE:

• 100 tonnes at 11m radius ; 50 tonnes at 19m radius

Ø DIVING / ROV SUPPORT CRANE:

• 1 x 15 tonnes Hagglund Pedestal Crane

ANCHORS: 2 x 10 tonnes “Danforth” on starboard side anchors with 56mm wire

Uncle John Holding LLC

8

• 7. DERRICK SYSTEM

DERRICK: 1X Dreco Welded Offshore Work Over Derrick; Designed in accordance with API specifications 4F and 8C; Derrick clear height is 24.4m, 7.92m foot square base and 2.74m foot square top; Operating static capacity is 150 tonnes and operating dynamic capacity is 120 tonnes. SUBSTRUCTURE: 1 X Substructure 6.48m x 10.67m x 1.52m high with a retractable floor of 6.10m x 6.40m to transport subsea tree from within derrick;

Uncle John Holding LLC

9

• 8. LIFE SAVING & FIRE FIGHTING EQUIPMENT

LIFE SAVING EQUIPMENT: Ø LIFE RAFTS:

• 2 x 25 man self inflating rafts (Forward Main Deck)
• 4 X 25 man self inflating rafts (Forward Tween Deck)
• 8 X 25 man self inflating rafts (Aft Main Deck)

Ø LIFE – JACKETS AND IMMERSION SUITS:

• 1 lifejacket is stowed at each bunk at all cabins and workspaces (Total 132)
• Additional 48 lifejackets in Forward Main Deck container
• Additional 55 lifejacket in Aft Main Deck Container

FIRE – FIGHTING EQUIPMENT: Ø DETECTION SYSTEM:

• 1 x SALWICO CS-3000
• 197 Smoke detectors, 2 thermal detectors, 3 flame detectors and 23 call points.

Ø INTERNAL FIRE FIGHTING:

• HALON 130A total flooding system

Ø HELIDECK FIRE FIGHTING:

• Portable foam units stored in location aft of heli-deck
• Fire and wash system

Uncle John Holding LLC

10

• 9. TRACK RECORDS

PROJECT NAME PROJECT LOCATION YEAR COMPLETE D CLIENT PROJECT DESCRIPTION Water Depth Mississippi Canyon Block 254 Gulf of Mexico Nov 2014 LLOG Exploration Installation of Steel Catenary Risers and Spool tie-in 4524 ft Mississippi Canyon Block 148 Gulf of Mexico March 2013 Apache Deepwater LLC Overboard, wet transfer, deployment and recovery

• f a 30-ton interchangeable

riserless intervention system (IRIS) 168 m
