Rogério de Lemos DSN 2006 WADS – June 2006 – 1

Idealised Fault Tolerant Idealised Fault Tolerant Architectural Element Architectural Element

Rog Rogé ério rio de Lemos de Lemos University of Kent, UK University of Kent, UK

Motivation – architectural fault tolerance; iFTE & propagation of exceptions; Case study – mining control system; Conclusions & future work;

Rogério de Lemos DSN 2006 WADS – June 2006 – 2

Motivation Motivation

Architectures are about structures:

unstructured approaches can reduce system

dependability by introducing more faults;

a good architecture should promote error confinement;

Architectural fault tolerance:

avoid the failure of systems

error detection and handling; fault handling;

components need to collaborate for handling certain

failure scenarios;

Rogério de Lemos DSN 2006 WADS – June 2006 – 3

Idealised Idealised Fault Tolerant Component Fault Tolerant Component

An architectural solution based on exception handling:

• idealised fault tolerant component

idealised fault tolerant component enables fault tolerance to be built into the system [Anderson & Lee 81]:

separation between normal and abnormal behaviour; provided and required services; local, interface and failure exceptions;

Rogério de Lemos DSN 2006 WADS – June 2006 – 4

Idealised Idealised Fault Tolerant Component Fault Tolerant Component

Exception handlers provides mechanisms for:

handling exceptional conditions so that the exception

can be masked;

backward recovery – roll back to a previous state; forward recovery – perform actions to correct the state by

• ther means;

signalling exceptions;

Handlers are provided for anticipated exceptions:

default handlers are provided for unanticipated

exceptions;

Rogério de Lemos DSN 2006 WADS – June 2006 – 5

Idealised Idealised Fault Tolerant C2 Component (iC2C) Fault Tolerant C2 Component (iC2C)

iC2C_internal iC2C_internal iC2C_bottom iC2C_bottom

upper_detector upper_detector lower_detector lower_detector

COTS

NormalActivity AbormalActivity

iC2C_top iC2C_top

detector_top detector_top detector_bottom detector_bottom

upper_detector

Error Detector (1) Error Detector (1) Error Detector (n) Error Detector (n)

• • •

abnormal_internal abnormal_internal abnormal_bottom abnormal_bottom

AbnormalActivity

Error Diagnosis Error Diagnosis Error Handler (n) Error Handler (n) Error Handler (1) Error Handler (1) abnormal_top abnormal_top

• • •

Rogério de Lemos DSN 2006 WADS – June 2006 – 6

Idealised Fault Tolerant Idealised Fault Tolerant Architectural Element ( Architectural Element (iFTE iFTE) )

Idealised fault tolerant architectural element ( Idealised fault tolerant architectural element (iFTE iFTE) );

• fault

fault-

• tolerant software component:

tolerant software component:

preventing the propagation of internal errors by constraining

its exceptional behaviour;

• fault

fault-

• tolerant software connector:

tolerant software connector:

coordinating exceptional behaviour among components; resolving potential mismatches; preventing the propagation of errors by handling them as

exceptions;

Rogério de Lemos DSN 2006 WADS – June 2006 – 7

Idealised Fault Tolerant Idealised Fault Tolerant Architectural Element ( Architectural Element (iFTE iFTE) )

Architectural solution/pattern:

peer-to-peer style; request/reply interaction;

<<component>> Provided IP_iFTE_S IP_iFTE_E <<component>> Normal <<component>> Abnormal IR_iFTE_S IR_iFTE_E <<component>> Required I_AC_E I_NC_S I_AC_S I_NC_E I_PC_E I_PC_S <<connector>> Coordinator I_CN_S I_CR_S I_CR_E I_CA_E <<element>> idealised fault-tolerant architectural element

Rogério de Lemos DSN 2006 WADS – June 2006 – 8

iFTE iFTE: Propagation Scenarios : Propagation Scenarios

Normal behaviour: Normal behaviour:

• internal services with no

exceptions;

• internal services with

exceptions:

• masked by internal handlers;
• masked by external handlers;
• requests external services with

no exceptions;

• requests external services with

exceptions;

• masked by internal handlers;
• masked by external handlers;

Exceptional behaviour: Exceptional behaviour:

• internal services with

exceptions:

• not masked by internal

handlers;

• not masked by external

handlers;

• requests external services with

exceptions;

• not masked by internal

handlers;

• not masked by external

handlers;

Rogério de Lemos DSN 2006 WADS – June 2006 – 9

iFTE iFTE: Propagation Scenarios : Propagation Scenarios

normal behaviour when requesting external services with no

exceptions;

Rogério de Lemos DSN 2006 WADS – June 2006 – 10

iFTE iFTE: Exception Propagation : Exception Propagation

Propagation of exceptions:

from components to

connectors;

from connectors to

components;

contexts for handling exceptions:

• component, roles and connectors;

exceptions meaningful for components and connectors;

• translation on the types of exceptions;

Rogério de Lemos DSN 2006 WADS – June 2006 – 11

iFTE iFTE: Exception Propagation : Exception Propagation

Propagation of exceptions:

from connectors to

connectors;

Rogério de Lemos DSN 2006 WADS – June 2006 – 12

Embedded System: Embedded System: Mining Control System Mining Control System

1 2 3 4 5 6 Mining environment Dump 1- Control system 2- Pump 3- Exhaustor 4- Water sensor (low level) 5- Water sensor (high level) 6- Methan sensor

Rogério de Lemos DSN 2006 WADS – June 2006 – 13

Embedded System: Embedded System: Mining Control System Mining Control System

Rogério de Lemos DSN 2006 WADS – June 2006 – 14

Embedded System: Embedded System: Mining Control System Mining Control System

Exception propagation when AirExtractor fails exception is propagated to OperatorInterface:

the whole system shuts down;

Rogério de Lemos DSN 2006 WADS – June 2006 – 15

Conclusions Conclusions

Fault tolerance at the architectural level:

error detection and handling:

application dependent; idealised Fault Tolerant Architectural Elements (iFTE);

• architectural solution/pattern based on exception handling;

fault handling:

not application dependent; reconfiguration support by CA action;

Rogério de Lemos DSN 2006 WADS – June 2006 – 16

Future Work Future Work

model the iFTE with AADL – Error Model; iFTE is application dependent and requires additional

assurances:

model iFTE with B and CSP for analysing the propagation of

exceptions;

identification of iFTE properties that can be applied to

architectures;

identification of iFTE test cases; automatic generation of Provided and Required components;
