Knowledge Representation for the Semantic Web Lecture 7: Answer Set - - PowerPoint PPT Presentation
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers Knowledge Representation for the Semantic Web Lecture 7: Answer Set Programming II Daria Stepanova partially based on slides by Thomas Eiter D5: Databases and
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Daria Stepanova
partially based on slides by Thomas Eiter
D5: Databases and Information Systems Max Planck Institute for Informatics
WS 2017/18
1 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
2 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Default negation “not a” means “a cannot be proved (derived)
using rules,” and that a is false by default (believed to be false).
❼ ❼ ❼ ❼
3 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Default negation “not a” means “a cannot be proved (derived)
using rules,” and that a is false by default (believed to be false).
❼ Strong negation ¬a (also −a) means that a is (provably) false ❼ Both default and strong negation can be used in ASP ❼ ❼
3 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Default negation “not a” means “a cannot be proved (derived)
using rules,” and that a is false by default (believed to be false).
❼ Strong negation ¬a (also −a) means that a is (provably) false ❼ Both default and strong negation can be used in ASP
“At a railroad crossing, cross the rails if no train approaches.” We may encode this scenario using one of the following two rules: walk ← at(X), crossing(X), not train approaches(X). (r1) walk ← at(X), crossing(X),−train approaches(X). (r2)
❼ r1 fires if there is no information that a train approaches. ❼ r2 fires if it is explictly known that no train approaches.
3 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Constraints are rules with empty head which exclude invalid models.
← q1, . . . , qm, not r1, . . . , not rn. kills answer sets that
❼ contain q1, . . . , qm, and ❼ do not contain r1, . . . , rn.
4 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Constraints are rules with empty head which exclude invalid models.
← q1, . . . , qm, not r1, . . . , not rn. kills answer sets that
❼ contain q1, . . . , qm, and ❼ do not contain r1, . . . , rn.
An equivalent version of the above rule is with a fresh predicate p: p ← q1, . . . , qm, not r1, . . . , not rn, not p.
4 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Constraints are rules with empty head which exclude invalid models.
← q1, . . . , qm, not r1, . . . , not rn. kills answer sets that
❼ contain q1, . . . , qm, and ❼ do not contain r1, . . . , rn.
An equivalent version of the above rule is with a fresh predicate p: p ← q1, . . . , qm, not r1, . . . , not rn, not p. Example: adjacent nodes cannot be colored with the same color ⊥ ← edge(X , Y ), colored(X , Z), colored(Y , Z).
4 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
The use of disjunction is natural
❼ to express indefinite knowledge: female(X) ∨ male(X) ← person(X). broken(left arm, robot1) ∨ broken(right arm, robot1). ❼
5 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
The use of disjunction is natural
❼ to express indefinite knowledge: female(X) ∨ male(X) ← person(X). broken(left arm, robot1) ∨ broken(right arm, robot1). ❼ to express a “guess” and to create non-determinism.
5 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c.
❼ ❼
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ ❼
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ Actually subset minimal:
a ∨ b. a ∨ c.
❼
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ Actually subset minimal:
a ∨ b. a ∨ c. Minimal models: {a} and {b, c}.
❼
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ Actually subset minimal:
a ∨ b. a ∨ c. Minimal models: {a} and {b, c}. a ∨ b. a ← b.
❼
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ Actually subset minimal:
a ∨ b. a ∨ c. Minimal models: {a} and {b, c}. a ∨ b. a ← b. Models: {a} and {a, b}, but only {a} is minimal.
❼
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ Actually subset minimal:
a ∨ b. a ∨ c. Minimal models: {a} and {b, c}. a ∨ b. a ← b. Models: {a} and {a, b}, but only {a} is minimal.
❼ But minimality is not necessarily exclusive:
a ∨ b. b ∨ c. a ∨ c.
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Semantics: disjunction is minimal (different from classical logic):
a ∨ b ∨ c. Minimal models: {a}, {b}, and {c}.
❼ Actually subset minimal:
a ∨ b. a ∨ c. Minimal models: {a} and {b, c}. a ∨ b. a ← b. Models: {a} and {a, b}, but only {a} is minimal.
❼ But minimality is not necessarily exclusive:
a ∨ b. b ∨ c. a ∨ c. Minimal models: {a, b}, {a, c}, and {b, c}.
6 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Extended Logic Programs An extended disjunctive logic program (EDLP) is a finite set of rules a1 ∨ · · · ∨ ak ← b1, . . . , bm, not c1, . . . , not cn (k, m, n ≥ 0) (1) where all ai, bj, cl are atoms or strongly negated atoms.
❼ ❼
❼ ❼ ❼
7 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Extended Logic Programs An extended disjunctive logic program (EDLP) is a finite set of rules a1 ∨ · · · ∨ ak ← b1, . . . , bm, not c1, . . . , not cn (k, m, n ≥ 0) (1) where all ai, bj, cl are atoms or strongly negated atoms. Semantics:
❼ Stable models (answer sets) of EDLPs are defined similarly as for
LPs, viewing −p as a new predicate.
❼
❼ ❼ ❼
7 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Extended Logic Programs An extended disjunctive logic program (EDLP) is a finite set of rules a1 ∨ · · · ∨ ak ← b1, . . . , bm, not c1, . . . , not cn (k, m, n ≥ 0) (1) where all ai, bj, cl are atoms or strongly negated atoms. Semantics:
❼ Stable models (answer sets) of EDLPs are defined similarly as for
LPs, viewing −p as a new predicate.
❼ Differences:
❼ I must not contain atoms p(c1, . . . , cn), −p(c1, . . . , cn) (consistency) ❼ I is a model of ground rule (1), if either {b1, . . . , bm} I or
{a1, . . . , ak, c1, . . . , cn} ∩ I = ∅.
❼
7 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Extended Logic Programs An extended disjunctive logic program (EDLP) is a finite set of rules a1 ∨ · · · ∨ ak ← b1, . . . , bm, not c1, . . . , not cn (k, m, n ≥ 0) (1) where all ai, bj, cl are atoms or strongly negated atoms. Semantics:
❼ Stable models (answer sets) of EDLPs are defined similarly as for
LPs, viewing −p as a new predicate.
❼ Differences:
❼ I must not contain atoms p(c1, . . . , cn), −p(c1, . . . , cn) (consistency) ❼ I is a model of ground rule (1), if either {b1, . . . , bm} I or
{a1, . . . , ak, c1, . . . , cn} ∩ I = ∅.
❼ Condition “M is the least model of P M” is replaced by “M is a
minimal model of P M” (P M may have multiple minimal models).
7 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Let P be the following program: man(dilbert). single(X) ∨ husband(X) ← man(X).
❼ ❼
❼ ❼
8 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Let P be the following program: man(dilbert). single(X) ∨ husband(X) ← man(X).
❼ As P is “not ”-free, grnd(P)M = grnd(P) for every M. ❼
❼ ❼
8 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Let P be the following program: man(dilbert). single(X) ∨ husband(X) ← man(X).
❼ As P is “not ”-free, grnd(P)M = grnd(P) for every M. ❼ Answer sets:
❼ M1 = {man(dilbert), single(dilbert)}, and ❼ M2 = {man(dilbert), husband(dilbert)}.
8 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
9 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
General idea: stable models are solutions!
Reduce solving a problem instance I to computing stable models of a LP Problem Instance I ProgramP Encoding: Model(s) Solution(s) ASP Solver
solutions of I are represented by models of P
Variant: Compute multiple models (for multiple / all solutions)
10 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Compared to SAT solving, ASP offers more features:
❼ transitive closure ❼ negation as failure ❼ predicates and variables ❼ ❼
11 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Compared to SAT solving, ASP offers more features:
❼ transitive closure ❼ negation as failure ❼ predicates and variables
Generic problem solving by separating the
❼ specification of solutions (“logic” PS) ❼ concrete instance of the problem (data D)
Program P
PS
Encoding: Program P
D
Encoding:
ASP Solver Model(s) Solution(s) PS Spec. Problem D Data
11 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Important element of ASP: Guess and Check methodology (or Generate-and-Test [Lifschitz, 2002]).
candidate solutions to a problem (program part G), and
solution if it is a proper solution for our problem (program part C).
❼ ❼
12 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Important element of ASP: Guess and Check methodology (or Generate-and-Test [Lifschitz, 2002]).
candidate solutions to a problem (program part G), and
solution if it is a proper solution for our problem (program part C). From another perspective:
❼ G: defines the search space ❼ C: prunes illegal branches.
Further discussion in [Eiter et al., 2000], [Leone et al., 2006], [Janhunen and Niemel¨ a, 2016], [Gebser and Schaub, 2016] (+ additional component for computing optimal solutions).
12 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Problem specification PPS (compact encoding) g(X) ∨ r(X) ∨ b(X) ← node(X)
← b(X), b(Y ), edge(X, Y ) ← r(X), r(Y ), edge(X, Y ) ← g(X), g(Y ), edge(X, Y ) Check
13 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Problem specification PPS (compact encoding) g(X) ∨ r(X) ∨ b(X) ← node(X)
← b(X), b(Y ), edge(X, Y ) ← r(X), r(Y ), edge(X, Y ) ← g(X), g(Y ), edge(X, Y ) Check Data PD: Graph G = (V, E) PD = {node(v) | v ∈ V } ∪ {edge(v, w) | (v, w) ∈ E}. Correspondence: 3-colorings ⇋ models: v ∈ V is colored with c ∈ {r, g, b} iff c(v) is in the model of PPS ∪ PD.
13 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
PD = {node(a), node(b), node(c), edge(a, b), edge(b, c), edge(a, c)}
14 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
PD = {node(a), node(b), node(c), edge(a, b), edge(b, c), edge(a, c)}
14 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: a directed graph represented by node( ) and edge( , ) and a starting node start( ). Problem: find a path beginning at the starting node which visits all nodes of the graph exactly once.
15 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: a directed graph represented by node( ) and edge( , ) and a starting node start( ). Problem: find a path beginning at the starting node which visits all nodes of the graph exactly once. inPath(X, Y ) ∨ outPath(X, Y ) ← edge(X, Y ).
← inPath(X, Y ), inPath(X, Y1), Y = Y1. ← inPath(X, Y ), inPath(X1, Y ), X = X1. ← node(X), not reached(X). Check reached(X) ← start(X). reached(X) ← reached(Y ), inPath(Y, X). Auxiliary Predicate
15 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: a directed graph represented by node( ) and edge( , ) and a starting node start( ). Problem: find a path/cycle1 beginning at the starting node which visits all nodes of the graph exactly once. inPath(X, Y ) ∨ outPath(X, Y ) ← edge(X, Y ).
← inPath(X, Y ), inPath(X, Y1), Y = Y1. ← inPath(X, Y ), inPath(X1, Y ), X = X1. ← node(X), not reached(X). ← not start reached. Check reached(X) ← start(X). reached(X) ← reached(Y ), inPath(Y, X). start reached ← start(Y ), inPath(X, Y ). Auxiliary Predicate
1The encoding for the Hamilthonian cycle contains red lines along with green ones. 15 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
PD = {node(a), node(b), node(c), node(d), edge(a, b), edge(a, c), edge(c, b), edge(b, c), edge(b, d), edge(d, c), edge(d, a), edge(a, d), start(a)}
16 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
PD = {node(a), node(b), node(c), node(d), edge(a, b), edge(a, c), edge(c, b), edge(b, c), edge(b, d), edge(d, c), edge(d, a), edge(a, d), start(a)}
16 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: information about members and courses of a computer science (CS) dept cs Problem:
❼ assign courses to members of the CS dept ❼ teachers must like the assigned course ❼ each member must teach 1-2 courses
17 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: information about members and courses of a computer science (CS) dept cs Problem:
❼ assign courses to members of the CS dept ❼ teachers must like the assigned course ❼ each member must teach 1-2 courses
PD: member(sam, cs). member(bob, cs). member(tom, cs).
17 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: information about members and courses of a computer science (CS) dept cs Problem:
❼ assign courses to members of the CS dept ❼ teachers must like the assigned course ❼ each member must teach 1-2 courses
PD: member(sam, cs). member(bob, cs). member(tom, cs). course(java, cs). course(ai, cs). course(c, cs). course(logic, cs).
17 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Input: information about members and courses of a computer science (CS) dept cs Problem:
❼ assign courses to members of the CS dept ❼ teachers must like the assigned course ❼ each member must teach 1-2 courses
PD: member(sam, cs). member(bob, cs). member(tom, cs). course(java, cs). course(ai, cs). course(c, cs). course(logic, cs). likes(sam, java). likes(sam, c). likes(tom, ai). likes(bob, java). likes(bob, ai). likes(tom, logic).
17 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Problem specification PPS: % assign a course to a teacher who likes it, by default teach(X, Y ) ←member(X, cs), course(Y, cs), likes(X, Y ), not − teach(X, Y ). % determine when a course should not be assigned to a teacher −teach(X, Y ) ←member(X, cs), course(Y, cs), teach(X1, Y ), X1 = X.
18 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Problem specification PPS: % assign a course to a teacher who likes it, by default teach(X, Y ) ←member(X, cs), course(Y, cs), likes(X, Y ), not − teach(X, Y ). % determine when a course should not be assigned to a teacher −teach(X, Y ) ←member(X, cs), course(Y, cs), teach(X1, Y ), X1 = X. % check each cs member has some course has course(X) ←member(X, cs), teach(X, Y ). ←member(X, cs), not has course(X).
18 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Problem specification PPS: % assign a course to a teacher who likes it, by default teach(X, Y ) ←member(X, cs), course(Y, cs), likes(X, Y ), not − teach(X, Y ). % determine when a course should not be assigned to a teacher −teach(X, Y ) ←member(X, cs), course(Y, cs), teach(X1, Y ), X1 = X. % check each cs member has some course has course(X) ←member(X, cs), teach(X, Y ). ←member(X, cs), not has course(X). % check each cs member has at most 2 courses ←teach(X, Y1), teach(X, Y2), teach(X, Y3), Y1 = Y2, Y1 = Y3, Y2 = Y3.
18 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
19 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ With the “guess and check paradigm”, one may use different
techniques to solve particular tasks E.g.,
❼ choice of exactly one element from a set ❼ computing maximum / minimum values (use double negation) ❼ testing a property for all elements in a set (iteration over a set) ❼ testing a co-NP hard property (saturation) ❼ modularization
❼ We do not discuss here saturation (see [Eiter et al., 2009])
Note: extensions of ASP allow to test properties of a set / choose elements elegantly
20 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Task: given a set, defined by predicate p(X), select exactly one
element from it (if nonempty).
❼ More general variant: p(
X, Y ), where X = X1, . . . , Xn,
X exactly one Y (if possible)
❼ Implicitly, already done in the above course assignment problem
21 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Task: given a set, defined by predicate p(X), select exactly one
element from it (if nonempty).
❼ More general variant: p(
X, Y ), where X = X1, . . . , Xn,
X exactly one Y (if possible)
❼ Implicitly, already done in the above course assignment problem
Select one element from a set: Normal rule encoding sel( X, Y ) ← p( X, Y ), not − sel( X, Y ). −sel( X, Y ) ← p( X, Y ), sel( X, Z), Yi = Zi. i = 1, . . . , m where Z = Z1, . . . , Zm,
21 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Example: Course assignment
❼ p(X, Y ) is member(Y, cs), course(X, cs), likes(Y, X) and
sel(X, Y ) is teach(Y, X).
❼ could define an auxiliary rule
p(X, Y ) ← member(Y, cs), course(X, cs), likes(Y, X) Select one element from a set: Disjunctive rule encoding sel( X, Y ) ← p( X, Y ), not − sel( X, Y ). −sel( X, Y ) ∨ −sel( X, Z) ← p( X, Y ), p( X, Z), Yi = Zi. i = 1, . . . , m
22 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Example: Course assignment
❼ p(X, Y ) is member(Y, cs), course(X, cs), likes(Y, X) and
sel(X, Y ) is teach(Y, X).
❼ could define an auxiliary rule
p(X, Y ) ← member(Y, cs), course(X, cs), likes(Y, X) Select one element from a set: Disjunctive rule encoding sel( X, Y ) ← p( X, Y ), not − sel( X, Y ). −sel( X, Y ) ∨ −sel( X, Z) ← p( X, Y ), p( X, Z), Yi = Zi. i = 1, . . . , m In some answer set solvers, special syntax is available (see ASP-Core2): 1{sel( X, Y ) : p( X, Y )}1 ← p( X, Z)
22 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Defining a predicate p in terms of its negation −p Greatest Common Divisor — Euclid-style
% base case
gcd(X, X, X) ← int(X), X > 1.
% subtract smaller from larger number
gcd(D, X, Y ) ← X < Y, gcd(D, X, Y1), Y = Y1 + X. gcd(D, X, Y ) ← X > Y, gcd(D, X1, Y ), X = X1 + Y. This is not easy to come up with and needs more care in Prolog.
23 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Greatest Common Divisor — ASP-style
% Declare when D divides a number N.
divisor(D, N) ← int(D), int(N), int(M), N = D ∗ M.
% Declare common divisors
cd(T, N1, N2) ← divisor(T, N1), divisor(T, N2).
% Single out non-maximal common divisors T
−gcd(T, N1, N2) ← cd(T, N1, N2), cd(T1, N1, N2), T < T1.
% Apply double negation: take non non-maximal divisor
gcd(T, N1, N2) ← cd(T, N1, N2), not − gcd(T, N1, N2).
24 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Testing a property, say Prop, for all elements of a set S without negation ❼ This may be needed in some contexts:
❼ in combination with other techniques, e.g., saturation (see [Eiter et al., 2009]), or ❼ if negation could lead to undesired behavior (e.g., cyclic negation). ❼ ❼ ❼
❼ ❼
❼
25 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Testing a property, say Prop, for all elements of a set S without negation ❼ This may be needed in some contexts:
❼ in combination with other techniques, e.g., saturation (see [Eiter et al., 2009]), or ❼ if negation could lead to undesired behavior (e.g., cyclic negation). ❼ walk through all elements of set S, from the first to the last element; ❼ check whether property Prop holds up to the current element y
⇔ holds for y and holds up to for x, where y is the successor of x;
❼ when Prop holds up to the last element, it holds for all elements of S
❼ ❼
❼
25 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Testing a property, say Prop, for all elements of a set S without negation ❼ This may be needed in some contexts:
❼ in combination with other techniques, e.g., saturation (see [Eiter et al., 2009]), or ❼ if negation could lead to undesired behavior (e.g., cyclic negation). ❼ walk through all elements of set S, from the first to the last element; ❼ check whether property Prop holds up to the current element y
⇔ holds for y and holds up to for x, where y is the successor of x;
❼ when Prop holds up to the last element, it holds for all elements of S
❼ Note: this is a form of finite induction ❼ Use an enumeration of S with predicates first( ), succ( , ), last( )
❼ Easy for static S, more involved for dynamically computed S
25 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Variant: no use of negation in checking that all nodes are reached
(do not immediately kill stable model candidate): ← node(X), not reached(X).
❼ Check that all nodes of the graph are reached via the selected edges
(inPath(X, Y )) by iteration (S = nodes of the graph)
❼ Use
❼ all reached upto( ) ❼ all reached
❼ Supply in the input an enumeration of the nodes via
first( ), succ( , ), last( )
❼ Alternative: build the enumeration dynamically in the progam, using
e.g. string comparison.
26 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
inPath(X, Y ) ∨ outPath(X, Y ) ← edge(X, Y ).
← inPath(X, Y ), inPath(X, Y1), Y = Y1. ← inPath(X, Y ), inPath(X1, Y ), X = X1.
reached(X) ← start(X). reached(X) ← reached(Y ), inPath(Y, X).
all reached upto(X) ← first(X), reached(X). all reached upto(X) ← all reached upto(Y ), succ(Y, X), reached(X). all reached ← last(X), all reached upto(X). reached = nodes
27 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
PD = {edge(a, b), edge(a, c), edge(c, b), edge(b, c), edge(b, d), edge(d, c), edge(d, a), edge(a, d), first(a), succ(a, b), succ(b, c), succ(c, d), last(d), start(a)}
28 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
PD = {edge(a, b), edge(a, c), edge(c, b), edge(b, c), edge(b, d), edge(d, c), edge(d, a), edge(a, d), first(a), succ(a, b), succ(b, c), succ(c, d), last(d), start(a)} all reached
all reached
all reached
all reached
28 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Some path guesses not reaching all nodes from a: all reached upto(c)
all reached upto(c)
all reached upto(a)
all reached upto(b)
all reached upto(a)
all reached upto(c)
29 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Do not reinvent the wheel: reuse solutions to basic problems. ❼ Program Splitting: syntactic means to
❼ develop larger programs by combining parts, and to ❼ compute answer sets layer by layer (by composition).
❼ ❼
30 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Do not reinvent the wheel: reuse solutions to basic problems. ❼ Program Splitting: syntactic means to
❼ develop larger programs by combining parts, and to ❼ compute answer sets layer by layer (by composition).
Program splitting Suppose (ground) P can be split into P = P1 ∪ P2, such that every atom A that occurs in P1 (“bottom part”) occurs in P2 (“top part”) only in rule bodies (i.e., A is “defined” entirely in P1). Then AS(P) =
M∈AS(P1) AS(P2 ∪ M).
AS(P) = set of answer sets of P
❼ Examples: ”stratified” programs, like GCD; guess&check ❼ Versions of ASP with modules, macros etc. are available
30 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
31 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
(see also http://en.wikipedia.org/wiki/Answer_set_programming)
asperix www.info.univ-angers.fr/pub/claire/asperix/ assat assat.cs.ust.hk/ clasp 1 potassco.sourceforge.net/#clasp/ cmodels www.cs.utexas.edu/users/tag/cmodels/ dlv 2 www.dbai.tuwien.ac.at/proj/dlv/ asptools research.ics.aalto.fi/software/asp/ me-asp www.mat.unical.it/ricca/me-asp/
www.kr.tuwien.ac.at/research/systems/omiga smodels www.tcs.hut.fi/Software/smodels/ wasp www.mat.unical.it/ricca/wasp/ xasp xsb.sourceforge.net/, distributed with XSB ....
1 + claspD, clingo, clingcon etc. (http://potassco.sourceforge.net/) 2 + dlvhex, dlvDB, dlt, dlv-complex, onto-dlv etc.
❼ ❼ ❼ ❼
32 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
(see also http://en.wikipedia.org/wiki/Answer_set_programming)
asperix www.info.univ-angers.fr/pub/claire/asperix/ assat assat.cs.ust.hk/ clasp 1 potassco.sourceforge.net/#clasp/ cmodels www.cs.utexas.edu/users/tag/cmodels/ dlv 2 www.dbai.tuwien.ac.at/proj/dlv/ asptools research.ics.aalto.fi/software/asp/ me-asp www.mat.unical.it/ricca/me-asp/
www.kr.tuwien.ac.at/research/systems/omiga smodels www.tcs.hut.fi/Software/smodels/ wasp www.mat.unical.it/ricca/wasp/ xasp xsb.sourceforge.net/, distributed with XSB ....
1 + claspD, clingo, clingcon etc. (http://potassco.sourceforge.net/) 2 + dlvhex, dlvDB, dlt, dlv-complex, onto-dlv etc.
❼ Many ASP solvers are available (mostly function-free programs) ❼ clasp was first ASP solver competitive to top SAT solvers ❼ another state-of-the-art solver is dlv ❼
32 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Different methods and evaluation approaches:
❼ resolution-based ❼ forward chaining ❼ lazy grounding AsperiX, Omiga ❼ translation-based (see below) ❼ meta-interpretation
33 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Different methods and evaluation approaches:
❼ resolution-based ❼ forward chaining ❼ lazy grounding AsperiX, Omiga ❼ translation-based (see below) ❼ meta-interpretation
Predominant solver approach intelligent grounding + model search (solving)
33 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Given a program P, generate a (subset) of grnd(P) that has the same models
❼ ❼ ❼ ❼ ❼
34 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Given a program P, generate a (subset) of grnd(P) that has the same models
More complicated than in SAT/CSP Solving:
❼ candidate generation (classical model) ❼ model checking (stability, foundedness!) ❼ ❼ ❼
34 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
Given a program P, generate a (subset) of grnd(P) that has the same models
More complicated than in SAT/CSP Solving:
❼ candidate generation (classical model) ❼ model checking (stability, foundedness!) ❼ for SAT, model checking is feasible in logarithmic space ❼ for normal propositional programs, model checking is PTime-complete ❼ for disjunctive propositional programs, model checking is co-NP-complete
34 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ ❼ ❼
❼ ❼
❼
❼ ❼ ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ ❼
❼ ❼
❼
❼ ❼ ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ Getting the “right” rules is difficult, already for positive programs ❼
❼ ❼
❼
❼ ❼ ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ Getting the “right” rules is difficult, already for positive programs ❼ Efficient grounding is at the heart of current systems
❼ dlv’s grounder (built-in); ❼ lparse (smodels), gringo (clasp)
❼
❼ ❼ ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ Getting the “right” rules is difficult, already for positive programs ❼ Efficient grounding is at the heart of current systems
❼ dlv’s grounder (built-in); ❼ lparse (smodels), gringo (clasp)
❼ Special techniques used:
❼ ❼ ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ Getting the “right” rules is difficult, already for positive programs ❼ Efficient grounding is at the heart of current systems
❼ dlv’s grounder (built-in); ❼ lparse (smodels), gringo (clasp)
❼ Special techniques used:
❼ “safe rules” (dlv): each variable in a rule occurs in the body in an
unnegated atom with non-built-in predicate (exception: X = c)
❼ ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ Getting the “right” rules is difficult, already for positive programs ❼ Efficient grounding is at the heart of current systems
❼ dlv’s grounder (built-in); ❼ lparse (smodels), gringo (clasp)
❼ Special techniques used:
❼ “safe rules” (dlv): each variable in a rule occurs in the body in an
unnegated atom with non-built-in predicate (exception: X = c)
❼ domain-restriction (smodels) ❼
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Grounding is a hard problem
bit(0). bit(1). (2) p(X1, ..., Xn) ← bit(X1), ..., bit(Xn). (3)
❼ In the worst case, grounding time is exponential in the input size ❼ Getting the “right” rules is difficult, already for positive programs ❼ Efficient grounding is at the heart of current systems
❼ dlv’s grounder (built-in); ❼ lparse (smodels), gringo (clasp)
❼ Special techniques used:
❼ “safe rules” (dlv): each variable in a rule occurs in the body in an
unnegated atom with non-built-in predicate (exception: X = c)
❼ domain-restriction (smodels) ❼ deductive db methods: semi-naive evaluation, magic sets, . . .
35 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Applied to ground programs. ❼
❼ ❼ ❼ ❼ ❼ ❼
❼
36 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Applied to ground programs. ❼ Early solvers (e.g. smodels, dlv): native methods
❼ inspired by Davis-Putnam-Logemann Loveland (DPLL) for SAT ❼ 3 basic operations: decision, propagate, backtrack ❼ special propagation for ASP, e.g., ❼ dlv: must-be-true propagation (supportedness), . . .
b:− not a. a:− not b. c:− not c, a. not a a c not c not b b not b c not c b
❼ ❼
❼
36 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Applied to ground programs. ❼ Early solvers (e.g. smodels, dlv): native methods
❼ inspired by Davis-Putnam-Logemann Loveland (DPLL) for SAT ❼ 3 basic operations: decision, propagate, backtrack ❼ special propagation for ASP, e.g., ❼ dlv: must-be-true propagation (supportedness), . . .
b:− not a. a:− not b. c:− not c, a. not a a c not c not b b not b c not c b
❼ important: heuristics (which atom/rule is next?) ❼ chronological backtrack-search improved by backjumping and look-back heuristics
❼
36 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Applied to ground programs. ❼ Early solvers (e.g. smodels, dlv): native methods
❼ inspired by Davis-Putnam-Logemann Loveland (DPLL) for SAT ❼ 3 basic operations: decision, propagate, backtrack ❼ special propagation for ASP, e.g., ❼ dlv: must-be-true propagation (supportedness), . . .
b:− not a. a:− not b. c:− not c, a. not a a c not c not b b not b c not c b
❼ important: heuristics (which atom/rule is next?) ❼ chronological backtrack-search improved by backjumping and look-back heuristics
❼ Stability check: unfounded sets, reductions to UNSAT (disj. ASP)
36 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Predominant to date: modern SAT techniques (clause driven
conflict learning, CDCL)
❼ Export of techniques from ASP to SAT (optimization issues) ❼ Genuine conflict-driven ASP solvers
❼ clasp, wasp
❼ Translation based solving: to
❼ SAT: assat, cmodels, lp2sat (multiple SAT solver calls) ❼ SAT modulo theories (SMT) aspmt ❼ Mixed Integer Programming (CPLEX backend)
❼ Cross translation: intermediate format to ease cross translation
❼ SAT modulo acyclicity ❼ interconnect graph based constraints with clausal constraints ❼ can postpone choice of the target format to last step solver).
❼ Portfolio solvers
❼ claspfolio: combines variants of clasp ❼ ME-ASP: multi-engine portfolio ASP solver
37 / 39
More about Logic Programs ASP Paradigm Programming Techniques Answer Set Solvers
❼ Strong negation, disjunction
❼ The guess and check methodology
❼ Element selection ❼ Use of double negation ❼ Iteration over a set ❼ Modularization
❼ Intelligent grounding and solving
38 / 39
Declarative problem-solving using the DLV system. In J. Minker, editor, Logic-Based Artificial Intelligence, pages 79–103. Kluwer Academic Publishers, 2000. Thomas Eiter, Giovambattista Ianni, and Thomas Krennwallner. Answer set programming: A primer. In Sergio Tessaris and Enrico Franconi et al., editors, Reasoning Web, Fifth International Summer School 2008, Bressanone Italy, August 30–September 4, 2009, Tutorial Lectures, number 5689 in LNCS, pages 40–110. Springer, 2009. Martin Gebser and Torsten Schaub. Modeling and language extensions. AI Magazine, 37(3):33–44, 2016.
Tomi Janhunen and Ilkka Niemel¨ a. The answer set programming paradigm. AI Magazine, 37(3):13–24, 2016. Nicola Leone, Gerald Pfeifer, Wolfgang Faber, Thomas Eiter, Georg Gottlob, Simona Perri, and Francesco Scarcello. The DLV System for Knowledge Representation and Reasoning. ACM Transactions on Computational Logic, 7(3):499–562, July 2006. Vladimir Lifschitz. Answer Set Programming and Plan Generation. Artificial Intelligence, 138:39–54, 2002.
