L bster The Enhanced So Solut lutio ion for r Fla lange Gasket In Insertio ion Presentation Content Company Introduction Gasket Insertion Tools Current Solutions & Disadvantages The Unique Solution The Advantages of

slide-1
SLIDE 1

L bster

The Enhanced So Solut lutio ion for r Fla lange Gasket In Insertio ion

slide-2
SLIDE 2

Presentation Content

  • Company Introduction
  • Gasket Insertion Tools Current Solutions & Disadvantages
  • The Unique Solution
  • The Advantages of using the Lobster Gasket Insertion Tool
  • The Lobster material specification
  • The Lobster GIT tool details
  • Ring Type Joint Lobster Chart
  • Industries Served
  • Reference List
  • Lobster Video
slide-3
SLIDE 3

Company Introduction

MS4C is a Dutch company based in Papendrecht, The Netherlands specialising in a range

  • f seals, in various shapes and sizes satisfying any applications and supplying a range of

industries. MS4C’s product portfolio comprises of:

  • Static & dynamic seals
  • Mechanical seals
  • Moulded products (rubber & engineering plastics)
  • Gaskets
  • Membranes
  • Vulcanisation
  • Lobster Gasket insertion tools
slide-4
SLIDE 4

Gasket Insertion Tools Current Solutions & Disadvantages…

The range of methods are currently being used to install gaskets, range from hands, simple tooling and a ‘one time’ gasket insertion tool: Some of today disadvantages for using current methods:

  • Safety - this continues to be key to most industries and improvement must be made
  • Only one gasket size per tool
  • Many tools are required for long distance pipelines
  • Tools can only be used once (‘one-time‘ usage)
  • Current tools are time consuming due to lengthy handling time
  • Current tools can only be used on RTJ‘s (Ring Joints)
  • Complex Logistics...
slide-5
SLIDE 5

L bster

The Unique Solution….

MS4C introduces the superior quality ‘Lobster’ Gasket Insertion Tools ensures a safer, faster, cost effective and more accurate method of installing gaskets between two mating flanges.

slide-6
SLIDE 6

The Advantages

The ‘Lobster’ range of gasket insertion tools has many benefits:

  • Increased Safety (being paramount in today’s industry)

Safe and quick Installation, reduced handling time

  • Easy to handle, one-hand operating process
  • Some companies operate with a hand free protocol,

the use of the ‘Lobster holding device means that the operator can work hands free offering significant advantages

*** Increased Safety, Cost Reductions and a positive Business Case guaranteed ! ***

Protocol

slide-7
SLIDE 7

The Advantages

  • Can be used on a variety of gaskets (from OD 50mm to OD 800mm)
  • RTJ’s - (R/BX/RX/SBX/SRX)
  • Spiral Wound Gaskets
  • Kammprofile Gaskets
  • Metal Jacketed Gaskets
  • Solid Gaskets
  • Non Asbestos Gaskets etc
  • Gasket installation in any flange position

*** Increased Safety, Cost Reductions and a positive Business Case guaranteed ! ***

slide-8
SLIDE 8

The Advantages

  • Cost Saving - durability and repetitive usage

means ROI after just 10 gasket installations

  • Multiple gasket dimensions per Lobster Tool (see Lobster details and RTJ charts)
  • Improved logistics
  • Used in a range of industries – Onshore, Offshore and Subsea
  • Global Distribution Channel
  • Patented Solution

*** Increased Safety, Cost Reductions and a positive Business Case guaranteed ! ***

slide-9
SLIDE 9

The Lobster Material Specification

The Lobster Gasket Insertion Tool is manufacturer in Europe using high quality materials.

  • The body of Gasket Insertion Tool, is high tensile

aluminium with anodic treatment, resistant against seawater, the same material as used in the aerospace, aviation and offshore industry.

  • The clamp is produced from steel with a special treatment

ensuring resistant against seawater.

  • The screws and nuts are stainless steel seawater resistant.

Meaning, we are on the safe side for the offshore usage, too!

slide-10
SLIDE 10

The Lobster Details

The Lobster Gasket Insertion Tool is available in 6 different tool sizes G

Tool Size Gasket Outer Diameter Gripper Size 'G' Tool Dimensions Tool Weight Box Weight Box Dimensions Total Weight 1 50mm – 80mm 6mm 29cm x 18cm x 2cm 0.4Kg 0.9kg 61cm x 44cm x 8cm 1.3kg 2 80mm – 150mm 6mm 41cm x 23cm x 2cm 0.5Kg 0.9kg 61cm x 44cm x 8cm 1.4kg 3 150mm – 250mm 6mm 55cm x 31cm x 2cm 1.0kg 1.5kg 71cm x 59cm x 8cm 2.5kg 4 250mm – 350mm 6mm 74cm x 43cm x 2cm 2.0kg 3.2kg 122cm x 90cm x 8cm 5.2kg 5 350mm – 500mm 8mm 84cm x 57cm x 2cm 4.5kg 3.2kg 122cm x 90cm x 8cm 7.7kg 6 500mm - 800mm 8mm 103cm x 86cm x 2cm 5.0kg 3.2kg 122cm x 90cm x 8cm 8.2kg Weight 0.30kg 2.50kg 0.90kg 7.30kg Stainless Steel Holding Device suitable for Lobster Tool Size 4, 5 and 6 Large Description Aluminum Holding Device suitable for Lobster Tool Size 1, 2 and 3 Aluminium Holding Device suitable for Lobster Tool Size 4, 5 and 6 Stainless Steel Holding Device suitable for Lobster Tool Size 1, 2 and 3 Size Small Large Small

Holding Devices in 2 sizes:

Working subsea Stainless Steel Holding Device is recommended.
slide-11
SLIDE 11

RTJ Lobster ‘GIT’ Chart

Loster Size 1 Lobster Size 2 Lobster Size 3 Lobster Size 4 Lobster Size 5 Lobster Size 6 50mm - 80mm 80m - 150mm 150mm - 250mm 250mm - 350mm 350mm - 500mm 500mm - 800mm R 12 R 21 R 36 R 48 R 55 R 68 R 13 R 22 R 37 R 49 R 56 R 69 R 14 R 23 R 38 R 50 R 57 R 70 R 15 R 24 R 39 R 51 R 58 R 71 R 16 R 25 R 40 R 52 R 59 R 72 R 17 R 26 R 41 R 53 R 60 R 73 R 18 R 27 R 42 R 54 R 61 R 74 R 19 R 28 R 43 R 91 R 62 R 75 R 20 R 29 R 44 R 63 R 76 R 30 R 45 R 64 R 77 R 31 R 46 R 65 R 78 R 32 R 47 R 66 R 79 R 33 R 90 R 67 R 80 R 34 R 92 R 81 R 35 R 99 R 93 R 100 RX 20 RX 23 RX 37 RX 49 RX 57 RX 69 RX 24 RX 39 RX 50 RX 63 RX 70 RX 25 RX 41 RX 53 RX 65 RX 73 RX 26 RX 44 RX 54 RX 66 RX 74 RX 27 RX 45 RX 91 RX 31 RX 46 RX 35 RX 47 RX 90 RX 99 RX 205 BX 150 BX 152 BX 156 BX 157 BX 158 BX 163 BX 151 BX 153 BX 169 BX 171 BX 159 BX 164 BX 154 BX 170 BX 172 BX 160 BX 165 BX 155 BX 161 BX 166 BX 162 BX 167 BX 168 Classification for RTJ Gaskets (RX series) Classification for RTJ Gaskets (BX series) Tool No. Classification for RTJ Gaskets (R series) Gasket Outer Diameter mm
slide-12
SLIDE 12

Industries Served

Oil & Gas Process Utilities OEMs Marine Steel Rolling Mills Aluminium Plants E.P.C’s / Contractors Solar Power Oil Tanking Wind Farms Aerospace/Automotive Subsea Pipelines Dredging FPSO’s
slide-13
SLIDE 13

Reference List

  • CONOCOPHILLIPS
ALASKA
  • SHELL RHEINLAND RAFFINERIE
GERMANY
  • DUXVALVES B.V.
THE NETHERLANDS
  • KREMSMÜLLER ANLAGENBAU
AUSTRIA
  • RAG
AUSTRIA
  • MIDCONTINENT ABERDEEN LTD
UNITED KINGDOM
  • NOVUS SEALING
SOUTH AFRICA
  • ABU ILLYAS TRADING LLC
OMAN
  • ROSNEFT B.V.
VIETNAM
  • KHAN CO LTD.
SOUTH KOREA
  • TNITECH CO LTD.
SOUTH KOREA
  • AND MORE …..
slide-14
SLIDE 14

Lobster Website & Video

The Lobster ‘GIT’ without a holding device https://youtu.be/RdNhLstITUc The Lobster ‘GIT’ with a holding device https://youtu.be/o2-oX7vIWTg www.Lobster-GIT.eu

slide-15
SLIDE 15

Thank you
