SMART CHARGING OF ELECTRIC VEHICLES IN RESIDENTIAL DISTRIBUTION GRIDS MARTIJN SCHOOT UITERKAMP, MSC. ABOUT ME BSc, MSc Applied Mathematics at University of Twente 2016: MSc thesis on robust charging of electric vehicles (EVs) Now:

slide-1
SLIDE 1

SMART CHARGING OF ELECTRIC VEHICLES IN RESIDENTIAL DISTRIBUTION GRIDS

MARTIJN SCHOOT UITERKAMP, MSC.

slide-2
SLIDE 2
  • BSc, MSc Applied Mathematics at

University of Twente

  • 2016: MSc thesis on robust charging
  • f electric vehicles (EVs)
  • Now: PhD student in “Energy group”

(collaboration between CAES and DMMP)

  • Area: optimization algorithms for

(devices within) smart grids

14/12/17 Smart charging of electric vehicles in residential distribution grids 2

ABOUT ME

slide-3
SLIDE 3

14/12/17 Smart charging of electric vehicles in residential distribution grids 3

RESEARCH OF THE “ENERGY GROUP”

  • Development of

management and control strategies for smart grids

  • Multidisciplinary: people

with background in

  • Embedded Systems
  • Electrical Engineering
  • Computer Science
  • Mathematics
  • …
slide-4
SLIDE 4
  • Residential EV charging - a field test
  • Strategy for EV charging
  • Coordination of multiple EVs

14/12/17 Smart charging of electric vehicles in residential distribution grids 4

OUTLINE

slide-5
SLIDE 5
  • % of cars that

were EVs:

  • 2010: 0.05%
  • 2015: 2.0%
  • 2016: 2.6%
  • Political ambition:

to sell only emission-free cars from 2030

  • nward

14/12/17 Smart charging of electric vehicles in residential distribution grids 5

ELECTRIC VEHICLES IN THE NETHERLANDS

RAPID INCREASE

slide-6
SLIDE 6
  • Lochem: test site (“proeftuin”) for smart grid management approaches
  • Field test in 2015
  • Charge 20 EVs

during the evening

  • Measure stability
  • f network

14/12/17 Smart charging of electric vehicles in residential distribution grids 6

A FIELD TEST

SETTING

slide-7
SLIDE 7
  • After 30 min.: melted

fuse on phase 3 due to

  • verloading!
  • Outage for 5 minutes

14/12/17 Smart charging of electric vehicles in residential distribution grids 7

A FIELD TEST

WHAT HAPPENED?

slide-8
SLIDE 8

18/12/17 Smart charging of electric vehicles in residential distribution grids 8

A FIELD TEST

LOAD UNBALANCE Figure 1 in “G. Hoogsteen et al.: 'Charging electric vehicles, baking pizzas, and melting a fuse in Lochem', CIRED - Open Access Proceedings Journal, 2017(1), p. 1629-1633” http://cired.net/publications/cired2017/pdfs/CIRED2017_0340_final.pdf

slide-9
SLIDE 9
  • Peak consumption
  • Consumption synchronization
  • Load unbalance

14/12/17 Smart charging of electric vehicles in residential distribution grids 9

A FIELD TEST

MAJOR PROBLEMS Conclusion: the current grid cannot accommodate large-scale EV charging without any control So what to do?

slide-10
SLIDE 10

14/12/17 Smart charging of electric vehicles in residential distribution grids 10

STRATEGY FOR EV CHARGING

ENERGY MANAGEMENT SYSTEM

slide-11
SLIDE 11
  • When is an EV available for charging?
  • How much must be charged?
  • What is the consumption of other devices?

14/12/17 Smart charging of electric vehicles in residential distribution grids 11

STRATEGY FOR EV CHARGING

PREDICTION

slide-12
SLIDE 12
  • Using predictions: determine optimal charging schedule for EVs
  • Here, optimal means “as flat as possible”
  • Apply mathematical
  • ptimization algorithms

14/12/17 Smart charging of electric vehicles in residential distribution grids 12

STRATEGY FOR EV CHARGING

PLANNING

slide-13
SLIDE 13

14/12/17 Smart charging of electric vehicles in residential distribution grids 13

STRATEGY FOR EV CHARGING

REAL-TIME CONTROL

  • What to do when predictions

turn out to be wrong / inaccurate?

  • Dealing with unexpected

behavior

slide-14
SLIDE 14

14/12/17 Smart charging of electric vehicles in residential distribution grids 14

COORDINATION OF MULTIPLE EVS

DEVICE CONTROL STRUCTURE

Fleet controller

Device controller Device controller Device controller

slide-15
SLIDE 15
  • Centralized: all

EVs together

  • Decentralized:

separately per EV and use feedback loop

14/12/17 Smart charging of electric vehicles in residential distribution grids 15

COORDINATION OF MULTIPLE EVS

CENTRALIZED VS. DECENTRALIZED

Optimize Overall profile Optimize Optimize Input Overall profile Optimize Input 1 1 1 All

slide-16
SLIDE 16
  • Fleet controller sends “target profiles” to device controllers
  • Devices: match consumption with target as well as possible
  • Repeat to cancel out over / undershoot

14/12/17 Smart charging of electric vehicles in residential distribution grids 16

COORDINATION OF MULTIPLE EVS

PROFILE STEERING

Optimize Overall profile Optimize Optimize Input 1 1 1

slide-17
SLIDE 17
  • Multi-commodity smart grids (electricity + heat)
  • Implementations in the “real” world
  • Cost allocation
  • ... and more …

14/12/17 Smart charging of electric vehicles in residential distribution grids 17

OUTLOOK

ONGOING SMART GRID RESEARCH AT THE UNIVERSITY OF TWENTE

slide-18
SLIDE 18
  • Our research: https://www.utwente.nl/ctit/energy/
  • A recent (and accessible!) paper on the Lochem field test:
  • G. Hoogsteen et al.: 'Charging electric vehicles, baking pizzas, and melting a fuse

in Lochem', CIRED - Open Access Proceedings Journal, 2017(1), p. 1629-1633

  • Many possibilities for BSc and MSc assignments, also in cooperation with

companies

14/12/17 Smart charging of electric vehicles in residential distribution grids 18

MORE INFORMATION

(OR: SHAMELESS PROMOTION…)

slide-19
SLIDE 19

14/12/17 Smart charging of electric vehicles in residential distribution grids 19

THANK YOU!

QUESTIONS?
