SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 1 -

Fascination ¡Blu

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 2 -

SMART SOLUTIONS TO DRIVE THE FUTURE

SINGULUS TECHNOLOGIES Fascination Blu Reloaded 2011 March 2011 Stephan Hotz BD-R/RE Cover-Layer System and Inline Solution

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 3 -

Agenda

• 1- Experience from INDIGO and BLULINE II
• 2- BD-R/RE LTH and HTL Technology
• 3- BD-R/RE Solutions

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 4 -

Milestones BLULINE II SL/DL

• 2004: Cooperation with SONY for BD 25 Film Technology
• February 2005: First BLULINEs BD 25 Film- and Spin-Technology
• April 2005: First playable BD 25
• October 2005: Start of delivery first BLULINEs BD 25 to customers
• March 2006: World premiere of BLULINE
• Summer 2006 Installed BLULINEs dominant at Customer site
• 2007 First year of Blu-ray Disc Mass Production with Singulus Equipment
• March 2007: Start of cooperation with Sony DADC for Wet-Embossing Technology
• May 2007: Startup wet-embossing process for BD 50 in Kahl
• January 2008: Integration of INDIGO into Singulus portfolio
• February 2008: World premiere of BLULINE II SL/DL
• As of today over 85 BD Lines installed

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 5 -

Singulus Blu-ray Disc Lines Installed Base World Wide

USA and SA 40 BD Lines all BD-ROM ASIA 20 BD Lines 8 BD-ROM 12 BD-R/RE EUROPE 26 BD Lines all BD-ROM

Total over 85 Blu-ray Disc Lines installed at more than 30 Customers

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 6 -

BLULINE II SL/DL

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 7 -

1 2 9 8 3 7 6 10 12 11 5

1 Molding 2 Cooling 3 Metallization Layer 0 4 Base-Resin 5 Pit-Resin 6 Pre-Curing 7 Wet-Embossing 8 Metallization Layer 1 9 Cover-Resin 10 Hardcoat-Resin 11 Barrier Layer 12 Final Inspection

BLULINE II SL/DL Material Flow

4

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 8 -

INDIGO BD-R/RE SL Material Flow

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 9 -

BD-R 4x HTL and BD-RE 2x HTL Inline Solution (1st Gen.) 6.5s cycle time

BLULINE I MoldPro Modulus/Sprinter BD-R molder Manual Buffer Air-blower Substrate scanner (optional) Cooling Conveyor Input Buffer Laser Marker

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 10 -

Agenda

• 1- Experience from INDIGO and BLULINE II
• 2- BD-R/RE HTL and LTH Technology
• 3- BD-R/RE Solutions

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 11 -

1,Molded Substrate 1.1mm Thickness 2,Reflecting Layer 3,Recording Layer (Dye) 4,Barrier Layer 5,Soft Cover Layer 25um thickness

• ①IMM

③Dye module Buffer unit with dye Scanner ②SP1 (Ag+) ④

Oven

Edge clean& surface clean Output buffer

⑤Soft Cover

Layer SP2 (ZnS.SiO2)

• r DC ZSSO

⑥hard Cover

Layer

⑦Hardcoat with final scanner and laser marker

Example for BD-R LTH Disc Structure (Gen. 1)

Aircushion

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 12 -

Hard Coating Cover Layer ZnS-SiO2 Si Cu-Alloy ZnS-SiO2 Oxide(ZSSO) Ag PC Substrate 1.1mm

Laser

Example for Layer structure of BD-R 4X and 6X HTL and Example for Layer structure of BD-RE 2X HTL

Hard Coating Cover Layer ZnS-SiO2 Oxide Phase-Change Oxide ZnS-SiO2 Oxide Ag-Alloy 1.1mm PC Substrate

Laser

BD-R BD-R/RE

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 14 -

Agenda

• 1- Experience from INDIGO and BLULINE II
• 2- BD-R/RE LTH and HTL Technology
• 3- BD-R/RE Solutions

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 15 -

1.

Interface to Customer Line

2.

Input handling

3.

Tempering Table

4.

Cover-Resin Dosing Track 1/2

5.

Cover-Resin IR-Treatment Track 1/2

6.

Cover-Resin UV-Spin-Cure Track 1/2

7.

Cover-Resin UV-Final-Cure

8.

Hardcoat-Resin Dosing Track 1/2

9.

Hardcoat-Resin Spinning Track 1/2

• 10. Hardcoat-Resin UV-Cure
• 11. Disc Handling
• 12. Turn table
• 13. Turnhandling
• 14. Transfer handling
• 15. SiN Sputtering
• 16. Turnhandling
• 17. Output handling
• 18. Interface to Customer line

BD-R/RE Cover-Layer System Material Flow Solution A

2 3 1 16 4 18 4 5 5 6 7 8 8 9 9

10

11 13 15 14 12

6

17

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 16 -

BD-R 1-6x and BD-RE 1-2x HTL Inline Solution (2nd Gen.)

Sprinter 9 BD-R/RE molder

Tempering Conveyor

Cover Layer System

2xRF 4xDC (R) 5xDC (RE)

Cover-Resin Hardcoat-Resin SiN-Backside-Coating Inline-Scanner BCA-Module BCA-Marker Laser-Marker

Interface I and Buffer I Interface II and Buffer II

BD-R Inline Solution:

Molder Conveyor Interface I / Buffer I Sprinter 9 Cover-Layer System Inline Scanner

BD-R Additional Invest:

Signal Tester TE/FE Checker Offline Inspection Layer Thickness Measuring One set of production tools

How to produce BD-R?

1. Make the decision to produce BD-R with HTL-

• r LTH- Technology

2. Get Equipment to produce BD-R 3. Get process package to produce BD-R 4x HTL 4. Obtain FLLA License for BD-R U$ 15.000,- for 5 years 5. Apply for your Disc MID code 6. Get your BD-R verified 7. BD-R production and royalty payment U$ cent 6.5 per disc 8. Get the BD-R disc and MID code accepted at the drive manufacturer

Auxiliary Equipment:

Interface II / Buffer II BCA-Module BCA-Marker Laser-Marker

Auxiliary Equipment

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 18 -

The Best meets The Best Singulus meets Oerlikon Your BD-R/RE Inline Solution

• Singulus Line

Oerlikon Sprinter World Class Process Partner

SINGULUS TECHNOLOGIES

Fascination Blu March 2011

• 19 -

YOUR TOTAL SOLUTION FOR BD
